BD136 PNP Transistor

4 Orders 1 Wish listed

৳10

Qty

Total price:

৳10

Overview
Reviews

Detail Description

The BD136 is a PNP medium power transistor commonly used in audio amplifier circuits, power amplifier stages, and general-purpose switching applications. It is designed to handle moderate current and voltage levels, making it suitable for both signal amplification and power control tasks.

This transistor is often used as a complementary device with NPN transistors such as BD135 or BD137 in push-pull and amplifier circuit designs. Due to its reliable performance and easy availability, the BD136 is widely used in analog electronics, audio systems, and educational projects.

Key Features:

• Transistor Type: PNP bipolar junction transistor (BJT).

• Medium Power Handling: Suitable for audio amplifiers and power stages.

• Complementary Use: Commonly paired with BD135 or BD137 in amplifier circuits.

• Stable Performance: Provides consistent and reliable operation in analog circuits.

• Through-Hole Package: Easy to mount on PCBs and compatible with heat sinks.

How it Works:

1. Current Control: A small base current controls a larger current flow between collector and emitter.

2. Signal Amplification: Amplifies low-level input signals in audio and analog circuits.

3. Switching Operation: Can be used as an electronic switch in control circuits.

4. Heat Management: Can be mounted with a heat sink for better thermal performance.

Applications:

• Audio amplifier circuits

• Power amplifier stages

• Signal amplification circuits

• Switching and control applications

• Educational and DIY electronics projects
